Desription |
Common parts |
Quantity |
| |
1 |
Complete P.M.G. upfit KIT (to 10/05/01) |
45-0060A |
1 |
|
|
|
Complete P.M.G. upfit KIT (from 10/05/01) |
45-0341A |
1 |
| |
2 |
P.M.G. cover (cover included in above kit) |
760-10562 |
1 |
|
|
3 |
Current P.M.G. rotor/stator repair kit |
45-1082 |
1 |
|
|
4 |
Current P.M.G. rotor/stator repair kit |
45-1082 |
1 |
|
|
5 |
P.M.G. crown (it fitted) |
See no. 1 |
1 |
|
|
6 |
N.D.E. bearing cap (to 10/05/01) |
660-10071 |
1 |
|
|
|
N.D.E. bearing cap (from 10/05/01) |
660-10864 |
1 |
|
|
7 |
N.D.E. bracket (to 10/05/01) |
660-10064 |
1 |
|
|
|
N.D.E. bracket (from 10/05/01) |
660-10860 |
1 |
|
|
8 |
N.D.E. bearing kit (to 10/05/01) |
45-0297 |
1 |
|
|
|
N.D.E. bearing kit (from 10/05/01) |
45-0340 |
1 |
|
|
9 |
N.D.E. bearing cartridge (to 10/05/01) |
462-12920 |
1 |
|
|
|
N.D.E. bearing cartridge (from 10/05/01) |
660-10862 |
1 |
|
|
10 |
Exciter stator 75mm |
366-40800 |
1 |
|
|
11 |
Main stator frame assy |
QMSN |
1 |
|
|
12 |
N.D.E. air inlet cover (industrial) |
660-11565 |
1 |
|
|
|
N.D.E. air inlet cover (marine) |
464-31600 |
1 |
|
|
13 |
Main rotor assy |
QMSN |
1 |
|
|
14 |
Exciter rotor 75 mm |
660-1010 |
1 |
|
|
15 |
Rotating rectifier assy |
450-16025 |
1 |
|
|
16 |
Diode FWD/REV & varistor kit |
RSK-6001 |
1 |
|
|
17 |
Main terminal board |
660-1005 |
1 |
|
|
18 |
Terminal box endpanel N.D.E. |
660-10653 |
1 |
|
|
19 |
Terminal box endpanel D.E. |
660-10652 |
1 |
|
|
20 |
Terminal box side panel |
660-10650 |
2 |
|
|
21 |
Terminal box LID |
660-10651 |
1 |
|
|
22 |
A.V.R. cover plate (access) |
450-15254 |
1 |
|
|
|
A.V.R. cover plate (blanking) |
450-14310 |
1 |
|
|
23 |
A.V.R. mounting bracket |
45-0742 |
1 |
|
|
24 |
A.V.R. MX341 (standard series 3) |
E000-23412/1P |
1 |
|
|
|
A.V.R. MX341 UL |
A040H491 |
1 |
|
|
|
A.V.R. MX321 |
E000-23212/1P |
1 |
|
|
|
A.V.R. MX321 TBA |
|
TBA |
|
|
25 |
Auxiliary terminal board |
003-14046 |
2 |
|
|
26 |
Heater 110-125 volt |
45-0373 |
1 |
|
|
|
Heater kit 110-125 volt to include term box for
retrofit |
TBA |
1 |
|
|
|
Heater 220-260 volt |
45-0374 |
1 |
|
|
|
Heater kit 220-260 volt to include term box for
retrofit |
A040G610 |
1 |
|
|
27 |
Terminal box for heaters |
45-0024 |
1 |
|
|
30 |
D.E. adaptor kit (SAE 0) |
45-0943 |
1 |
|
|
|
D.E. adaptor kit (SAE 0.5) |
45-0944 |
1 |
|
|
|
D.E. adaptor kit (SAE 1) |
45-0937 |
1 |
|
|
|
D.E. adaptor kit (SAE 0 round) |
45-0945 |
1 |
|
|
|
D.E. adaptor kit (SAE 00) |
45-0942 |
1 |
|
|
31 |
D.E. screen (included in adaptor kits) |
See no. 30 |
2 |
|
|
32 |
D.E. louvre (SAE 0 & 0.5 & 1) |
45-0658 |
1 |
|
|
|
D.E. louvre (SAE 00) |
45-0657 |
1 |
|
|
33 |
Coupling kit SAE 14 |
45-0788 |
1 |
|
|
|
Coupling kit SAE 18 |
45-0789 |
1 |
|
|
|
Coupling kit SAE 17.75 |
45-0791 |
1 |
|
|
|
Coupling kit SAE 21 |
45-0790 |
1 |
